Model NO.	WDWH02
Specification	500mm450mm450mm
Trademark	Windoo/OEM
Origin	China
HS Code	8544110000
Production Capacity	5000

Packaging & Delivery

Package Size 60.00cm * 50.00cm * 50.00cm Package Gross Weight 80.000kg

Product Description

0.1-0.8mm Wire Diameter Single axis front CNC Voice Core Winding machine /Front uniaxial general transformer special winding machineSingle axis front CNC Winding machineTechnical Data:

Model:	WDWH02 Single Axis Front CNC Voice Winding Machine
Applicable wire diameter	0.1-0.8mm
Winding width	100mm
Cable width:	140mm
Spindle diameter:	12mm
Control method:	CNC controller
Number of spindles:	1 spindle
Winding reel	1 spool
Rotation diameter:	170mm
Spindle motor	DC brushless 400W
Cable motor	Stepper motor
Machine speed	3000/6000rpm
Number of Memory	groups 0-9999
Machine Power Supply	AC220V/50HZ
Machine Weight	30kg
Machine Size	500mm450mm450mm
Machine weight:	35kg
Scope of application	EI transformers, high frequency transformers, pulse transformers, inductance coils, adaptive power supplies

The performance characteristics of the winding machine have the following advantages:1. Using microcomputer design, teaching input, easy data setting;2. The installation settings can be changed for different occasions, and the scope of use is wider;3. The winding data is set by the button, which is convenient and accurate, and can reach the purpose of multi-segment and multi-speed;4. Adjust the winding point and width by teaching input, and the data setting is easy and accurate;5. The power supply circuit adopts an improved anti-interference circuit, which has stronger anti-interference ability;6. The winding shaft adopts CPLD decoding speed measuring circuit, and the positioning is more accurate;7. The stepper motor of the cable axis is driven by constant current chopper, with fast cable speed and high precision;8. The position of the cable spool can be input with the teach key, and the current position of the cable spool can be displayed9. Automatic forward and reverse winding, synchronous cable arrangement, multi-segment number of turns counting.10. The installed parameters can be changed for different specifications of machines and occasions, and the range of use is wide.11. Each group of winding programs independently provides a variety of operation and operation mode options, and the operation is more flexible. 12. According to customer needs: connect/disconnect DC24V 12W winding shaft sensor.13. The minimum displacement unit of the cable shaft can be set by the button, which can be applied to multi-he specification screws. 14. Error alarm function, which can display error information and have a prompt tone. 15. Power supply: AC220V+10% commercial power16. The plastic lagging table part of the machine adopts: fine-tuning function, easy to use in adjustment17. The wire rack and the wire head are fixed on the wire rod, which can realize the function of synchronous movement18. Uses: various switching power supply transformers, supplies, Japanese type, inductance coils, relay coils
